Heavy Duty A-Justa-Foot™ 121 Series
(Stainless Steel)
Complete with Anti-slip pads
| Part No. | Size | A | B | C | D | E | Rating |
| 121/40/M8/60 | 40xM8 | 40 | 60 | 30 | 18 | M8 | 500kg |
| 121/40/M10/60 | 40xM10 | 40 | 60 | 30 | 18 | M10 | 700kg |
| 121/60/M12/90 | 60xM12 | 60 | 90* | 40 | 17 | M12 | 1200kg |
| 121/60/M12/190 | 60xM12x190 | 60 | 190 | 40 | 17 | M12 | 1200kg |
| 121/60/M16/90 | 60xM16 | 60 | 90* | 40 | 17 | M16 | 2000kg |
| 121/60/M16/190 | 60xM16x190 | 60 | 190 | 40 | 17 | M16 | 2000kg |
| 121/60/M20/90 | 60xM20 | 60 | 90* | 40 | 17 | M20 | 3500kg |
| 121/60/M24/90 | 60xM24 | 60 | 90* | 40 | 17 | M24 | 4500kg |
| 121/90/M12/90 | 90xM12 | 90 | 90* | 48 | 19 | M12 | 1200kg |
| 121/90/M12/190 | 90xM12x190 | 90 | 190 | 48 | 19 | M12 | 1200kg |
| 121/90/M16/90 | 90xM16 | 90 | 90* | 48 | 19 | M16 | 2000kg |
| 121/90/M16/190 | 90xM16x190 | 90 | 190 | 48 | 19 | M16 | 2000kg |
| 121/90/M20/90 | 90xM20 | 90 | 90* | 48 | 19 | M20 | 3500kg |
| 121/90/M24/90 | 90xM24 | 90 | 90* | 48 | 19 | M24 | 4500kg |
| 121/125/M12/90 | 125xM12 | 125 | 90* | 45 | 22 | M12 | 1200kg |
| 121/125/M16/90 | 125xM16 | 125 | 90* | 45 | 22 | M16 | 2000kg |
| 121/125/M16/190 | 125xM16x190 | 125 | 190 | 45 | 22 | M16 | 2000kg |
| 121/125/M20/90 | 125xM20 | 125 | 90* | 45 | 22 | M20 | 3500kg |
| 121/125/M24/90 | 125xM24 | 125 | 90* | 45 | 22 | M24 | 4500kg |
* 90 BASE ALSO AVAILABLE WITH BOLTDOWN HOLES
